• TS1-400 TD3(PR221DS)

  • TS1 series moulded case circuit breaker ( here below as breaker ) is suitable for AC 50HZ ( or 60HA), rated insulation voltage 800V, rated working voltage 690V and below, DC 250V and below, rated current of 12.5A-1600A circuit, is used for distributing electric energy. Making non-frequent closing&breaking in the normal condition, and doing the protection when the circuit and equipment are oveload, short circuit or lacking voltage.
    The breaker cpmplies with the standard of IEC60947-1、IEC60947-2、GB14048.2 etc.

  • Frame Current：160A, 250A, 400A, 630A

    Pole：3/4P

    Breaking Cpacity：36KA, 50KA, 70KA, 100KA, 150KA

    Tripping：TD3(PR221DS)

    Protection：AC

    Operating mode：Toggle handle，Rotate handle，Extended rotate handle，Motor operating handle

    Standard：IEC60947-2 Appendix B；IEC255-4和IEC1000；Fault Tripping Protection
