• CS1-630/3P CD3

  • CS1 series moulded case circuit breaker ( here below as breaker ) is suitable for AC 50HZ ( or 60HA), rated insulation voltage 800V, rated working voltage 690V and below, DC 250V and below, rated current of 12.5A-1600A circuit, is used for distributing electric energy. Making non-frequent closing&breaking in the normal condition, and doing the protection when the circuit and equipment are oveload, short circuit or lacking voltage.
    The breaker cpmplies with the standard of IEC60947-1、IEC60947-2、GB14048.2 etc.

  • Frame Current：100A, 225A, 400A, 630A

    Pole：3/4P

    Breaking level Icu：C type（fundamental ），L type（Standard ），M type（relatively high breaking ），H type（high breaking）

    Tripping：CD3(CM1E)

    Usage：For protecting the distribution system of transformer power

    Protection：Long-time delay protection, short circuit with fixed delay short protection, short circuit instantaneous protection, neutral line protection

    Indication: local indication, long-distance indication
