• CS1-1250/3P

  • CS1 series moulded case circuit breaker ( here below as breaker ) is suitable for AC 50HZ ( or 60HA), rated insulation voltage 800V, rated working voltage 690V and below, DC 250V and below, rated current of 12.5A-1600A circuit, is used for distributing electric energy. Making non-frequent closing&breaking in the normal condition, and doing the protection when the circuit and equipment are oveload, short circuit or lacking voltage.
    The breaker cpmplies with the standard of IEC60947-1、IEC60947-2、GB14048.2 etc.

  • Frame Current：63A, 100A, 160A, 225A, 250A, 400A, 630A, 800A

    Pole：3/4P

    Breaking level Icu：C type（fundamental form），L type（Standard form），M type（relatively high breaking form），H type（high breaking form）

    Tripping：TMD

    Installation：Fix，Plug-in，Plug-out
    Operating Mode：Rotate handle operating，motor operating This Circuit breaker with isolation function
